OrthoGraph 2.0 – A new web platform for BIM model management & building survey

OrthoGraph 2.0 is a complete web platform for BIM model management & building survey with a consolidated API for third-party extensions. Besides, this newest application contains web viewer, mobile app improvements etc.

OrthoGraph 2 provides a full-featured platform for 2/3D floor plan surveys and BIM model management on both Apple iOS and Android mobile devices.

OrthoGraph 2 comes up with a new API (application programming interface) that facilitates to incorporate enterprise functionalities directly into the OrthoGraph 2 platform. The enterprise feature can bring up-to-date building systems data through systems like CAFM, CMMS and any kind of ERP (enterprise resource planning) software, arranging graphical data side-by-side with facilities data.

OrthoGraph 2 serves the CAFM (Computer-aided facilities management ) and CMMS (computerized maintenance management system) process both onsite and in the office via its new web 3D model viewer.

OrthoGraph 2 comprises of an extensive 2D and 3D library, along with HVAC, Fire and Safety and Electrical symbols.

The new version of OrthoGraph can deal with curved walls. It is possible to draw, measure, and export these walls in all formats with their associated data.

To get more information, go through the following link https://www.orthograph.net/

Watch the following online demonstration of OrthoGraph 2.

Video Source: OrthoGraph
